0.08 × 0.10 mm spot, removable cover
Works with your software
Fine enough for photo engraving and small text. The cover slides off for lens cleaning and shields your eyes while it runs.
LightBurn, LaserGRBL, AtomStack app. Wi-Fi or USB.
AtomStack Sold by the exclusive authorized dealer for Germany
AtomStack F4N Honeycomb
- Sturdy Honeycomb Frame: Facilitates rapid heat dissipation, ensures durability with efficient smoke exhaust, and enhances cutting precision for improved overall performance.
- Larger Working Area: Spacious work surface designed to accommodate the needs of most laser engravers, measuring 410mm*420mm*22.5mm.
- Enhanced Cutting Effect: Ensures smooth edges, clean work, and a stain-free outcome.
- Desktop Double Protection: Prevents project over-burning while safeguarding both your work surface and the produced work.
- Upgrade Your User Experience: Comes equipped with 4 Anti-Slip Pads & 6 Platens to enhance stability and securely fix carving materials.
- Protect Your Hands: Featuring a smooth-edged corner design to prevent any harm or injury to your hands.
Comparison of F2, F3, F4N, and F8 Honeycomb Panels
 |
 |
 |
 |
|
| Model | F2 | F3 | F4N | F8 |
| Price | $76 | $109 | $76 | $139 |
| Working Area Size | 400mm*400mm (15.75" × 15.75")±5mm |
410mm*410mm (16.14" × 16.14")±5mm |
400mm*400mm (15.75" × 15.75")±5mm |
392mm x 810mm |
| Frame Size | 490mm*445mm (19.29" × 17.52")±5mm |
460*425mm (18.11" × 16.73")±5mm |
420mm*410mm (16.54" × 16.14")±5mm |
400*850mm （15.75" x 33.46"）±5mm |
| Height | 21mm | 20mm | 22.5mm | 17mm |
| Precision Scales | Yes | No | No | No |
| Fixing Attachment | Yes | Yes | Yes | Yes |
| Detachability | No | No | Yes | No |
| Material | thickened all-metal structure | thickened all-metal structure | thin-metal designs | thickened all-metal structure |
| Key Features | Stability, Durability, Reduced Vibrations | Portability, Effortless cleaning and Enhanced smoke removal | Portability, Setup Flexibility | Stability, Durability, Reduced Vibrations |
| Anti-slip Pads | Yes | Yes | Yes | Yes |
| Packing Weight | 2.95KG | 1.9KG | 2.5KG | 5.2KG |
| Compatibility |
① Max Series —— A70 Max, A40 Max, A20 Max（To cover the entire workspace, multiple pieces are required）
|
① Max Series —— A70 Max, A40 Max, A20 Max （To cover the entire workspace, multiple pieces are required） ② Unibody Series —— A24 Ultra, A48 Ultra, A24 Pro ③ Ace Pro V2 Series —— A10 Pro V2, A20 Pro V2, A40 Pro V2 ④ Pro Series —— A70 Pro, A30 Pro, A40 Pro |
① Max Series —— A70 Max, A40 Max, A20 Max（To cover the entire workspace, multiple pieces are required） ② Unibody Series —— A24 Ultra, A48 Ultra, A24 Pro ③ Ace Pro V2 Series —— A10 Pro V2, A20 Pro V2, A40 Pro V2 ④ Pro Series —— A70 Pro, A30 Pro, A40 Pro |
① A20 Max |
| Shop Now | Shop Now | Shop Now | Shop Now |
EUR 63,99
EUR 109,99-42%
incl. 19% VAT. Free shipping in Germany.
- Order today, ships within 24–48 h. Delivery in Germany 3–7 business days, free. EU: EUR 9.90.
- German VAT invoice by email. Business and school purchases welcome.
- 12-month warranty handled by Makerish in Germany. Spare parts on the shelf.
- 14-day right of withdrawal for EU consumers.
What the 20W changes
Twice the optical power of the A10 in the same frame. That means cutting 10 mm plywood in one pass, engraving dark acrylic without a second run, and finishing a batch of coasters before the coffee is cold.
Twice the optical power of the A10 in the same frame: cutting 10 mm plywood in one pass, engraving dark acrylic without a second run.
Aluminium frame, guide rails
Works with your software
0.02 mm accuracy at 400 mm/s on a 400 × 365 mm bed.
LightBurn, LaserGRBL, AtomStack app. Wi-Fi or USB.
Works with your software
Works with your software
LightBurn, LaserGRBL, AtomStack app. Wi-Fi 2.4G or USB.
LightBurn, LaserGRBL, AtomStack app. Wi-Fi or USB.
Air assist ready
Works with your software
Add the air kit and the machine switches it on and off per job.
LightBurn, LaserGRBL, AtomStack app. Wi-Fi or USB.
Cross-cursor positioning
Works with your software
Put the job exactly where the material is, without a test run.
LightBurn, LaserGRBL, AtomStack app. Wi-Fi or USB.
Assembled in minutes, safe by default
Assembled in minutes, safe by default
Frame arrives pre-assembled. Flame detection, tip-over alarm and resume-after-power-cut are built in.
Frame arrives pre-assembled. Flame detection, tip-over alarm and resume-after-power-cut are built in.
Engraves
- Wood
- Bamboo
- Cardboard
- Plastic
- Leather
- PCB
- Anodized aluminum
- Painted metal
- 304 mirror steel
- Dark glass
- Ceramics
- Cotton
- Slate
Cuts
- Plywood up to 10 mm
- Black acrylic
- Cardboard
- Non-woven fabric
- Thin plastic sheet
- Sponge
- Thin steel plate
Clear acrylic and bare metal are not diode jobs. For those, look at the A70 Max or ask us about infrared modules.
Specifications
From the AtomStack data sheet. If a number matters to your project and is missing here, ask us and we measure it on the demo unit.
From the AtomStack data sheet. If a number matters and is missing, ask us and we measure it on the demo unit.
Download data sheet (PDF)| Model | A20 Pro V2A20 Pro V2 |
|---|---|
| Optical output | 20W (input 120W)20W (input 120W) |
| Wavelength | 455 +/- 5 nm455 +/- 5 nm |
| Spot size | 0.08 × 0.10 mm0.08 × 0.10 mm |
| Engraving area | 400 × 365 mm400 × 365 mm |
| Max speed | 400 mm/s400 mm/s |
| Accuracy | 0.02 mm0.02 mm |
| Motion | Guide railsGuide rails |
| Focus | ManualManual |
| Connectivity | USB, Wi-Fi 2.4 GHzUSB, Wi-Fi 2.4 GHz |
| Software | LightBurn, LaserGRBL, AtomStack PC & appLightBurn, LaserGRBL, AtomStack PC & app |
| File formats | JPG, JPEG, SVG, PNG, BMP, PDF, G-code, DXFJPG, JPEG, SVG, PNG, BMP, PDF, G-code, DXF |
| Safety | Tip-over alarm (over 15 degrees), flame detection (with Z2 Z-axis slider), resume engraving, cross positioningTip-over alarm, flame detection, resume, cross positioning |
| Certification | IEC 60825, CE, FCC, RoHS, FDA, PSE, UKCAIEC 60825, CE, FCC, RoHS, FDA, PSE, UKCA |
| Warranty | 12 months, handled by Makerish in Germany12 months, handled by Makerish in Germany |
In the box
- A20 Pro V2 frame, pre-assembled axes
- 20W laser module with protective cover
- Power supply (EU plug) and USB cable
- Protective goggles
- Focus gauge, tools, spare screws
- Test material pack
- Quick-start guide (EN/DE)
We open and inspect every machine before it ships, so the box is resealed with a Makerish inspection label. Confirm list against the current AtomStack packing list before publishing.
Frequently bought with the A20
Software that works with it
Free options cover most jobs. LightBurn is what small businesses end up on. We help you set up either.
AtomStack Studio / app
Free. Phone or PC. Good for first jobs and quick tags.
Free. Phone or PC. Good for first jobs and quick tags.
LightBurn
Paid, one-time. Layers, camera alignment, batch runs. Our recommendation for selling.
Paid, one-time. Layers, camera alignment, batch runs. Our pick for selling.
LaserGRBL
Free, Windows. Simple and stable for engraving.
Free, Windows. Simple and stable for engraving.
A10, A20 or A40?
Same frame family, three power levels. The A20 is the middle choice for a reason.
Same frame family, three power levels. The A20 is the middle choice for a reason. Swipe to compare.
| A10 Pro V2 | A20 Pro V2 this page | A40 Pro V2 | |
|---|---|---|---|
| Optical power | 10W | 20W | 48W / 24W |
| Working area | 410 × 380 mm | 400 × 365 mm | 385 × 400 mm |
| Max speed | 400 mm/s | 400 mm/s | 500 mm/s |
| Cuts plywood | up to 6 mm | up to 10 mm | up to 20 mm |
| Air assist | Optional | Optional (bundle) | F60 included |
| Best for | Hobby, larger sheets | Side business, small runs | Daily cutting |
| Price | EUR 378.99 | EUR 543.99 | EUR 1,365.00 |
Bought from Makerish means
We are the only authorized AtomStack dealer for Germany, with a written agreement. That changes what happens after you click buy.
Ships from Germany
Stocked in our warehouse. No customs, no import VAT, no six-week wait.
Stocked in our warehouse. No customs, no import VAT, no six-week wait.
Warranty handled here
12 months. Write to us, we diagnose, we send the part or swap the module. Nothing goes overseas.
12 months. We diagnose, send the part or swap the module. Nothing goes overseas.
Parts on the shelf
Modules, belts, lenses, controller boards. Most replacement parts ship within 48 hours.
Modules, belts, lenses, boards. Most replacement parts ship within 48 hours.
14-day returns
Statutory withdrawal for EU consumers. Unused, original packaging. Details in the Widerrufsbelehrung.
Statutory withdrawal for EU consumers. Unused, original packaging.
Reviews
Makerish opened in 2026. The first customer reviews for this listing are still being collected; we do not import or buy reviews. Below are published independent reviews of the A20 Pro V2.
Ask an owner question“AtomStack machines are elegant, user-friendly, yet powerful and precise. Any maker would be fortunate to own one.”
“Clearly a lot of thought has gone into the AtomStack. From the software right through to its user-friendly features.”
FAQCommon questions
Does the A20 Pro V2 need an enclosure?
Not required, but recommended for indoor use with smoke. Goggles are in the box; an enclosure with extraction keeps the room clean and the noise down.
